Description Frequency Response: 20Hz~20kHz, -0.3dBu, S/N Ratio: >110 dBu, Distortion(THD): <0. 01at1kHz(0dBu), Cross-talk: <100dB below full scale Input Section: Type: Balanced XLR, Max. Input Level: 15dBu, Impedance: 1M/ΩStereo; 500kΩ/MONO Output Section: Type: Balanced XLR, Max. Output Level (bypass): 15dBu, Impedance: <500Ω Digital Procssing: 24-bit sigma – delta converters, 48kHz Sampling Rates Display: 20x2LCD Display For Parameters Setting And Function Select Power Supply: AC~95V-264V FUSE 250VAC/2A FAST Dimension(LxWxH): 82x205x44CM Weight: 2.88kg 48kHz sampling rate, 40-bit DSP processor, 24-bit AD/DA convertor Input processing includes Gain, Mute, Link, High-cut, Low -cut, Noise gate, 5PEQ, Phase, Delay Output processing includes Crossover, 6PEQ, Gain, Mute, Compressor/Limiter, Phase, Delay, Link Every input and output can do matrix assign freely Adjustable PEQ frequency, Gain and Bandwidth, the gain step is 0.1dB, we can choose style: Peak, H-shelf, L-shelf, LP-6dB, LP-12dB, HP-6dB, HP-12dB The style of all High-cut, Low-cut filter and Distributor Unit: Butterworth, Linkwitz- Riley, Bessel, Slope is-6dB/oct ~-48dB/oct Adjustable compressormiter threshold, soft knee, ratio, attached time and release time. Noise gate’s threshold, hold time, attached time and release time can be adjustment The parameters of input and output adjusting are linkable, revisable input and output channels All delay module’s delay time can reach over 680ms the step is: 0.021ms Parameter setting of each channel can copy freely, build-in signal generator Input and Output on the front panel are equipped with 5-segment high precision level indicators, key indicators, security protection function 30 user preset, 1factory preset, device parameter and single preset file can save in computer; it also can download from computer and save in the device The device itself can store multiple preset parameters and recall freely. With PC software, one-key online made the operation more convenient USB and RS232 controlling ports, Online remote control and 255 units linkable through Rs485.
